Title: “HTTP Error 401.1″ error message when Msiexec.exe updates an MSI file in Windows Vista, in Windows 7, in Windows Server 2008, or in Windows Server 2008 R2″

Symptoms:
Assume that you deploy an application to a client computer that is running one of the following operating systems by using System Center Configuration Manager 2012:
•Windows Vista
•Windows 7
•Windows Server 2008
•Windows Server 2008 R2
When the deployment of the application is finished, the Microsoft Installer Package (MSI) file is removed from the local drive. Then, the ConfigMgr client updates the MSI source list by accessing the content server. This behavior is controlled by the self-healing functionality. When the self-healing functionality is triggered, Msiexec.exe tries to access the content path anonymously instead of by using the credentials of the user who currently logs on the client computer. However, the Secure Windows Initiative (SWI) guidelines do not allow anonymous access to content servers. Therefore, you receive the following error message:

The full article can be found here:
http://support.microsoft.com/kb/2619572

Example command line: Wusa.exe c:\temp\Windows6.1-KB982018-v3-x64.msu /quiet /norestart

To simplify the installation I have made a small script the will parse all the files in the same directory as the script and install all files which ends with .MSU automatically. It can both be used to distribute the hotfixes using software distribution or in a Task Sequence so you can install the updates during OSD.

To use it simply save the script in the same folder as you Windows 7 hotfixes you want to deploy and then create a package and program with the folder as package source and the command line configured as below.

I strongly recommend that you allow configuration manager to restart the computer, otherwise the user can be prompted by the Windows Update agent to restart within 10  minutes.

If you need to troubleshoot it run it with allow user to interact, then you will see the updates being displayed in a command prompt.

Installmsu.vbs script:

Next


It is truly a great place to start looking for information about Configuration Manager 2012.

You find it here: http://social.technet.microsoft.com/wiki/contents/articles/7075.system-center-2012-configuration-manager-survival-guide.aspx

But in the case where we have users that are local admins, I know it is a pain but the real-world, I try to do one of these tricks as well to at least make it harder for them to uninstall the FEP client.

1. Remove the Uninstallstring registry value for the FEP client, then the FEP client is no longer visible under uninstall a program in the Control Panel. I use this really simple script to achieve it:

oReg.DeleteValue HKEY_LOCAL_MACHINE,strKeyPath,strStringValueName


2. The second option is to replace the uninstall key with a script prompting the user that it is not allowed to uninstall the FEP client, getting the below result.

I simply copy a vbscript with the below content to the C:\windows directory and then run it from there, sample script for the promptscript:


MsgBox "FEP is not allowed to be uninstalled", 0, "FEP Uninstaller"

Sample script for replacing the FEP uninstall string:


const HKEY_LOCAL_MACHINE = &H80000002

Set oReg=GetObject("winmgmts:{impersonationLevel=impersonate}!\\.\root\default:StdRegProv")

strKeyPath = "SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\Microsoft Security Client"

strStringValueName = "UninstallString"

strvalue = "wscript.exe c:\windows\fepuninst.vbs"

oReg.SetStringValue HKEY_LOCAL_MACHINE,strKeyPath,strStringValueName,strValue

I hope this can be helpful, it isn’t pretty but it does it’s job.

This is the script I use:


dim Computerdn, strComputerName

dim Args

Set WshShell = WScript.CreateObject("WScript.Shell")

'----Get Computer DN------

Set objADSysInfo = CreateObject("ADSystemInfo")

ComputerDN = objADSysInfo.ComputerName

strcomputerdn = "LDAP://" & computerDN

Set objADSysInfo = Nothing

'-----Read commandline---

Set args = WScript.Arguments

end function

Then I run it from a package in the task sequence. It must be run after the “Setup Windows & ConfigMgr” step, so that the computer is restarted after it is joined to the domain.
The account which executes the script must have permissions in the AD to set the AD Description. Just replace the %desc% with the variable you want to use or static value if you want to use that.

If you want to be prompted for an AD description when the Task Sequence starts create a Collection variable for the OSD Collection with an empty value like this:

I use the following to simple steps in my Windows 7 deployment task sequence to prevent the computer monitor for entering power save.

The first step simple configures the current power scheme to not turn off the monitor when power is connected, this command must run after the “Setup Windows and ConfigMgr” step so that the computer has restart with the locally installed OS:

When the installation of the OS is complete i simply restore the Power Scheme back to default by running the following command. When the OS deployment is complete I simply configure the power option either by using Group policy Preferences or Configuration Manager.

• System Center 2012: Endpoint Protection
• CM 2012 Application Management part 1
• CM 2012 Application Management part 2

It was great fun and a really great event! Thanks Cornerstone for a great event and thanks to everyone who attended, looking forward to next year!

When R3 came along the SCCM 2007 R3 requires a hotfix(KB977384) which restarts a lot of services on the computer during installation for instance ccmexec, WMI and so on, if a Task Sequence or application installation runs it will stop and return error.
so I wrote a little vbscript which uses a .MIF file to report the installation status back to the SCCM server. It will report any errors back to the SCCM server so that it is easy to troubleshoot.

The script can be downloaded here: Install

To implement the script do the following:

1. Copy the needed installation media to a folder with the following sub-folders.
   Note: to save space I deleted files in the WAIK directory from the Configuration Manager SP2 installation source as these files are not needed to install the admin console.
2. Save the downloaded vbscript to the folder you just created and rename it to install.vbs.
3. Create a Unattend.ini file in the ConfigMgr_sp2 folder with the following content, you need to change the server name to your SCCM Primary Site server.

[Identification]
Action=InstallAdminUI
[Options]
SMSInstallDir=c:\program files\Configuration Manager 2007
ParentSiteServer=SCCM1
SDKServer=SCCM1

4. In SCCM Create a Package with the source folder beeing the folder structure just created.
5. In the package properties configure the following under the reporting tab: (this is used to match the .mif file generated by the script with the package)

6. Create a program with the following settings:

7. If you want to display the installation progress in a cmd windows to the users, configure the program to “Allow users to interact with this program”
8. Add the package to your Distribution Points
9. Advertise the program to a test collection and start testing.

I hope this can be useful for more than me.

When creating the report create a prompt in the report called varcollection

Report Query:

order by SYS.Netbios_Name0


SQL query for the varcollection prompt:


begin
if (@__filterwildcard = '')
select distinct CollectionID, Name from v_Collection order by Name
else
select distinct CollectionID, Name from v_Collection
WHERE CollectionID like @__filterwildcard
order by Name
end


If you have tried this you know that the Ccmsetup.exe installs a service and the exits in the user context so that control is returned to the vbscript, cmd file or whatever method you use to run Ccmsetup.

There are two ways of solving this:

1. Run Ccmsetup.exe with the /noservice switch then ccmsetup runs the setup in the user with which you triggered the installation and not using  a service in System context.

2.Use vbscript that checks for an active process called “ccmsetup.exe” and wait for it to exit.

I thought of writing a script for this and then I found this excellent discussion on a forum: http://www.tek-tips.com/viewthread.cfm?qid=911251

That script will work for Ccmsetup as well. Below is the modified script for ccmsetup.exe


Set WshShell = Nothing
Set WshShell = WScript.CreateObject("WScript.Shell")
WshShell.Run "ccmsetup.exe SMSSITECODE=020 FSP=SCCM01", 0, True
Wscript.Sleep 5000
set svc=getobject("winmgmts:root\cimv2")
sQuery="select * from win32_process where name='ccmsetup.exe'"
set cproc=svc.execquery(sQuery)
iniproc=cproc.count
Do While iniproc = 1
wscript.sleep 5000
set svc=getobject("winmgmts:root\cimv2")
sQuery="select * from win32_process where name='ccmsetup.exe'"
set cproc=svc.execquery(sQuery)
iniproc=cproc.count
Loop
set cproc=nothing
set svc=nothing
Set WshShell = Nothing
